Battery Replacement MPX1400 / YR-MPX1400-B00 Manipulator

Model Covered: YR-MPX1400-B00

Material Required:

BATTERY, ASSY,  HW1471600-BA/191140-1

(HW1470715-BA with conversion cable) For S-, L-axis encoder (MPX1400-B**)

BATTERY, ASSY, HW1471600-BB 191141-1

(HW1470715-BB with conversion cable) For U-, R-axis encoder (MPX1400-B**)

BATTERY, ASSY, HW1471600-BC 191142-1

(HW1470715-BC with conversion cable) For B-, T-axis encoder (MPX1400-B**)

TAPE, PIPE, TEFLON, 1/2 IN X 1296 IN,TB4501/151720-1
