Battery Replacement MPO10 / YR-MPO0010-A00 Manipulator

Model Covered: YR-MPO0010-A00

Material Required:

BATTERY, PACK, S AXIS ENCODER, MPO10, EXCEPT FOR B00/C00A 196330-1

For S-axis encoder (A**, E**, F**) (HW1471496-A with conversion cable)

BATTERY, PACK, L/U AXIS ENCODER, MPO10, EXCEPT FOR B00/C00A 196331-1

For L- and U- axis encoders (A**, E**, F**) (HW1471496-B with conversion cable)

TAPE, PIPE, TEFLON, 1/2 IN X 1296 IN,TB-4501/151720-1
