Battery Replacement MPO10 / YR-MPO0010-COO Manipulator

Model Covered: YR-MPO0010-C00

Material Required:

BATTERY, PACK, S/L AXES, EXCEPT FOR B**, HW1471600-DA 192154-1

For S-axis encoder (for C**A) (HW1373234-A with conversion cable)

BATTERY, PACK, U/R AXES, EXCEPT FOR B**, HW1471600-DB 192155-1

For L- and U- axis encoders (for C**A) (HW1373234-B with conversion cable)

TAPE, PIPE, TEFLON, 1/2 IN X 1296 IN,TB-4501/151720-1
