Material Required: Battery 180718-1 / ER6BD-WK77P 3.6V
A CMOS backup is recommended before replacing the battery.
1. Remove the CPU Board by removing the two screws located at the top and bottom of the board.
2. Connect the new battery to the spare connector CN115 to the left of the current battery installed.
DO NOT UNPLUG THE OLD BATTERY BEFORE INSTALLING NEW BATTERY.
3. Disconnect the Old battery from CN114 and remove from the holder.
4. Mount the new battery into the holder and arrange the battery cable.
5. Install CPU board and tighten screws.
